LaAlO3 Lanthanum Aluminate Single Crystal Substrate for High-Temperature Superconducting & Giant Magnetoresistance Thin Film
  • Nombre
  • Nombre

LaAlO3 Lanthanum Aluminate Single Crystal Substrate for High-Temperature Superconducting & Giant Magnetoresistance Thin Film

Nombre De La Marca: Crystro
Número De Modelo: SCR-2026-27-01
Tiempo De Entrega: 5-6 SEMANAS
Condiciones De Pago: T/T, Western Union, MoneyGram, Paypal
Información detallada
Descripción del producto
Información detallada
Lugar de origen:
Porcelana
Fórmula molecular:
LaAlO3
Método de crecimiento:
Czochralski
Estructura cristalina:
sistema de cristal hexagonal
Enreje constante:
a=5,357A c=13,22A
Dureza de Mohs:
6.5
Densidad:
6,52g/cm3
Punto de fusión:
2080°C
Constante dieléctrica:
el valor de la carga
Coeficiente de expansión térmica:
10x10-6/K
Pérdida de bronceado:
~3x10-4@300K,~0,6x10-4@77K
Resaltar:

LaAlO3 single crystal substrate

,

Lanthanum aluminate substrate for superconductors

,

High-temperature superconducting thin film substrate

Descripción del producto

LaAlO3 Lanthanum Aluminate Single Crystal Substrate for High-Temperature Superconducting & Giant Magnetoresistance Thin Film



Lanthanum aluminum oxide (LaAlO3) is a high-temperature superconducting single-crystal substrate material. It is an excellent substrate material for the epitaxial growth of high-temperature superconducting thin films and giant magnetic thin films. Its superior dielectric properties make it suitable for the fabrication of low-loss microwave amplifiers and dielectric resonant devices.

Size Φ76.2mm
Thickness 0.5mm or customer customization
Polishing Double or single throwing
Crystal optics <100>,<110>,<111>
Surface Roughness Ra Ra≤1nm
Crystalline precision ±0.2°
Positioning edge accuracy 2° (customizable within 1°)

Lanthanum aluminate (LaAlO3) single crystal is a kind of industrial, large-size HTS thin film substrate single crystal material. LaAlO3 crystal matches well with many kinds of perovskite structure materials, and is the substrate material for epitaxial growth of high temperature superconducting films and giant magnetoresistance films. At the same time, lanthanum aluminum crystals have a low dielectric constant and good microwave dielectric performance, so they are suitable for low-loss microwave amplifier devices and dielectric resonance applications.



Main characteristics:

Low dielectric loss

The lattice matches well

Small coefficient of thermal expansion

Good chemical stability

Good thermal stability

Typical applications:

High-temperature superconducting thin film extension substrate

Giant magnetic film outer lining

Microwave amplification and dielectric resonance
